Complete product lines extracted from our verified 2025/2026 engineering manuals: Precision Connectors (1.0mm to N-Type), Coaxial Adapters, Ultra-Low Loss Phase-Stable Cables (PhasePro / PhaseX / MasterVNA to 110GHz), and RF Attenuators & Terminations.
Directly structured from Lixunda 2025/2026 product manuals. Select categories below or use instant keyword search across all models.
Ultra-precision coaxial connectors for 5G/6G, aerospace radar, and high-frequency microwave testing with low VSWR < 1.15. Air dielectric interface.
| Frequency | 1.0mm (110G), 1.85mm (65G), 2.4mm (50G), 2.92mm (40G) |
| Impedance | 50 Ω |
| VSWR | ≤ 1.15 : 1 (Typical) |
| Body Material | Passivated Stainless Steel (SUS303) / Gold Plated |
Comprehensive line including Male/Female straight, right angle, 2-hole/4-hole flange mount, bulkhead, end-launch, microstrip, and PCB solder mount.
| Frequency | SMA (DC-18/26.5 GHz), SSMA (DC-40 GHz) |
| Dielectric | PTFE / Air / Glass Seal (Hermetic) |
| Mating Cycles | ≥ 500 Cycles |
| Temperature | -65°C to +165°C |
Full detent, limited detent, and smooth bore push-on configurations. Ideal for high-density modular radar, phased array antennas, and compact telecommunication cards.
| Frequency | SMP (DC-40G), SSMP (DC-65G), BMA (DC-22G), QMA (DC-18G) |
| Detent Options | Full Detent, Limited Detent, Smooth Bore |
| VSWR | ≤ 1.20 : 1 |
| Features | Radial & Axial Misalignment Compensation |
Ruggedized weather-resistant connectors for 5G cellular base stations, broadcast, and industrial RF. Low PIM ≤ -160 dBc, IP67/IP68 waterproof options.
| Frequency | N (DC-18G), TNC (DC-11G/18G), BNC (DC-4G), DIN/4.3-10 |
| PIM Rating | ≤ -160 dBc @ 2x20W (4.3-10 / 7/16 DIN) |
| Plating | Tri-Metal (Cu-Sn-Zn) / Silver / Nickel Plated |
| Waterproof | IP67 / IP68 Sealed |
Male-to-Female, Male-to-Male, Female-to-Female adapters across all standard and precision interfaces: 1.0mm (110G), 1.85mm (65G), 2.4mm (50G), 2.92mm (40G), 3.5mm, SMA, SMP, N.
| Series Available | 1.0-1.0, 1.85-1.85, 2.4-2.4, 2.92-2.92, 3.5-3.5, SMA-SMA, N-N, SMP-SMP |
| VSWR | ≤ 1.10 @ 18GHz, ≤ 1.20 @ 65GHz, ≤ 1.30 @ 110GHz |
| Material | Passivated Stainless Steel / Beryllium Copper Gold Plated |
| Mounting | Straight, 4-Hole Flange, Bulkhead, Hermetic |
Seamless interconnect between different RF series: 3.5mm-SMP, SMA-SMP, SMA-BMA, SMA-TNC, SMA-BNC, SMA-N, SMA-MCX, SMA-DIN, and N-L16.
| Configurations | 3.5mm to SMP/N, SMA to SMP/BMA/TNC/BNC/N/DIN/MCX |
| Coupling | Threaded to Snap-on / Push-on / Bayonet |
| Impedance | 50 Ω Standard |
| Naming Standard | SMA/N-KJG (Stainless Steel Left-to-Right Contact) |
Micro-porous PTFE dielectric with silver-plated copper tape & braid. Extreme phase stability over flexure (<±3° @ 40GHz) and temperature (-55°C to +125°C).
| Models | ZLA240-ZLA760 (PhasePro), ZLB150-ZLB2000S (PhaseX) |
| Phase Stability | < ±1.5° @ 26.5GHz, < ±3.0° @ 50GHz |
| Velocity | 83% - 85% Vp |
| Shielding | > 90 dB (High RFI isolation) |
Heavy-duty stainless steel / polyurethane armored test jumpers engineered for daily lab calibration and production testing. Superior flex life and amplitude/phase retention.
| Frequency Models | ZVNA18 (18G), ZVNA26 (26.5G), ZVNA40 (40G), ZVNA50, ZVNA67, ZVNA110 (110G) |
| Phase / Flex | ±1.5° @ 26.5GHz / ±3.5° @ 110GHz (360° wrap) |
| Armor Options | NA Series (Armor) / PA Series (Heavy Armored) |
| Crush Resistance | > 2500 N / 100mm |
Complete line of formable semi-flexible cables (ZR086, ZR141), copper jacketed semi-rigid (ZB020C-ZB250), military RG (RG316, RG142, RG400), and Low-PPM phase knee-free cables (ZLK).
| Series | MilHP (ZLF), Ultrabend (ZLG), Semi-Flex (ZR), Semi-Rigid (ZB), RG Series |
| Standard | MIL-C-17 / GJB Specification |
| Bend Radius | Zero spring-back (ZB) / Ultrabend micro-bend (ZLG) |
| Outer Jacket | FEP / PFA / Polyurethane / Bare Copper / Tinned Copper |
Precision microwave matched terminations for laboratory calibration, isolators, power dividers, and transmitter dummy loads. Low reflection across full bandwidth.
| Connectors | 1.85mm, 2.4mm, 2.92mm, 3.5mm, SMA, SSMA, SMP, TNC, BNC, N, 4.3-10, DIN |
| Power Rating | 1W, 2W, 5W, 10W, 25W, 50W, 100W+ (Heatsink available) |
| VSWR | ≤ 1.05 @ 18GHz, ≤ 1.15 @ 40GHz, ≤ 1.25 @ 67GHz |
| Impedance | 50 Ω ± 0.5 Ω |
Ultra-flat frequency response fixed attenuators with high power handling and low temperature coefficient of attenuation (TCA).
| Series | 1.85mm-67 (67G), 2.4mm-50 (50G), 2.92mm-40 (40G), SMA-18 (18G), SMA-06 (6G) |
| Attenuation Values | 1, 2, 3, 6, 10, 20, 30, 40 dB (±0.3dB to ±0.8dB accuracy) |
| Power | 2W, 5W, 10W, 25W, 50W CW |
| VSWR | ≤ 1.15 : 1 (Typical) |
Standard preset breakaway torque wrenches to prevent connector damage and ensure repeatable electrical connection. Mechanical VNA calibration kits (SOLT).
| Applicable Interfaces | 1.0mm, SSMA, SMA, 3.5mm, 2.92mm, 2.4mm, 1.85mm, TNC, N, DIN, J599 |
| Preset Torque | 4 in-lbs, 5 in-lbs, 8 in-lbs (0.9 N·m), 14 in-lbs (1.7 N·m), etc. |
| Accuracy | ± 4% Guaranteed |
| Cal Kits | 3.5mm / SMA / 2.92mm / N Type SOLT Precision Kit |
No matching product models found
Try searching by series name (e.g. SMA, PhasePro, 110GHz, N-Type, Attenuator, ZLA, ZLB).
Lixunda RF interconnect components are deployed in over 50 countries across telecommunications, defense, test & measurement, and aerospace.
Low PIM (≤ -160 dBc), high-power connectors (4.3-10, 7/16 DIN, N-Type) and jumper assemblies for Massive MIMO antennas and RRUs.
Hermetically sealed glass-to-metal microwave components, MilHP cables, and vibration-proof SSMP/SMP blind-mate arrays compliant with MIL-STD-202.
MasterVNA & MasterTest armored cables, precision 1.0mm/1.85mm/2.4mm/2.92mm adapters, and mechanical calibration kits for Keysight/R&S/Anritsu VNAs.
Non-magnetic connectors for MRI systems, RF ablation devices, 77GHz automotive millimeter-wave radar links, and FAKRA telematics interfaces.
Equipped with 50+ imported Japanese automatic CNC lathes, automatic stripping machines, and Keysight/Rohde & Schwarz high-end VNAs up to 110GHz, we guarantee micrometric machining tolerances (±0.005mm) and consistent batch electrical performance.
Submit your part numbers, technical requirements, or custom drawings. Our senior RF application engineers will review and respond within 24 hours with quotation and datasheets.
Fill in your required product specs, quantity, and part numbers below:
